FC 300 Design Guide
How to Program
" 10-** CAN fie ldbu s
Par.
No. #
Parameter description Default value 4-set-up Change
during
operation
Conver-
sion index
Type
10-0* Common settings
10-00 CAN protocol [1] Device Net All set-ups FALSE - Uint8
10-01 Baudrate se lect [20] 125 Kbps All set-ups FALSE - Uint8
10-02 MAC ID 63 All set-ups FALSE 0 Uint8
10-05 Readout Transmit Error Counter 0 All set-ups TRUE 0 Uint8
10-06 Readout Receive E rror Counter 0 All set-ups TRUE 0 Uint8
10-07 Readout Bus Off Counter 0 All set-ups TRUE 0 Uint16
10-1* DeviceNet
10-10 Process data type selection App. dependent 1 set-up TRUE - Uint8
10-11 Process Data Config Write 0 All set-ups FALSE 0 Uint8
10-12 Process D ata Config Read 0 All set-ups FALSE 0 Uint8
10-13 Warning Parameter 63 All set-ups FALSE 0 Uint8
10-14 Net Reference [0] Off All set-ups TRUE - Uint8
10-15 Net Control [0] Off All se t-ups TRUE - Uint8
10-2* COS filters
10-20 COS Filter 1 65535 All set-ups FALSE 0 Uint16
10-21 COS Filter 2 65535 All set-ups FALSE 0 Uint16
10-22 COS Filter 3 65535 All set-ups FALSE 0 Uint16
10-23 COS Filter 4 65535 All set-ups FALSE 0 Uint16
10-3* Parameter a cces s
10-30 Parameter Data Types [0] Errata 1 All set-ups TRUE - Uint8
10-31 Array index 0 All set-ups TRUE 0 Uint16
10-39 Devicenet F parameters 0 All set-ups TRUE 0 U int32
" 13-** Smart logic c ontrol
Par.
No. #
Parameter description Default value 4-set-up Change
during
operation
Conver-
sion index
Type
13-1* Comparators
13-10 Comparator Operand [0] DISABLED 2 set-ups FALSE - Uint8
13-11 Comparator Operator [1] ≈ 2set-ups FALSE - Uint8
13-12 Comparator Value 0.000 2 set-ups FALSE -3 Int32
13-2* Timers
13-20 SL control timer 0.000 s 1 se t-up FALSE -3 TimD
13-4* Logic rules
13-40 Logic Rule Boolean 1 [0] False 2 set-ups FALSE - Uint8
13-41 Logic Rule Operator 1 [0] DISABLED 2 set-ups FALSE - Uint8
13-42 Logic Rule Boolean 2 [0] False 2 set-ups FALSE - Uint8
13-43 Logic Rule Operator 2 [0] DISABLED 2 set-ups FALSE - Uint8
13-44 Logic Rule Boolean 3 [0] False 2 set-ups FALSE - Uint8
13-5* Smart logic ctrl.
13-50 SL control mode [0] Off 2 set-ups FALSE - U int8
13-51 SL control event [0] False 2 set-ups FALSE - Uint8
13-52 SL control action [0] DISABLED 2 set-ups FALSE - Uint8
*
default setting ()display text []value for use in communication via serial communication port
264
MG.33.B
6.22 - V LT is a registered Danfoss trademark

Danfoss FC 300 Specifications

General

Enclosure	IP20
Approvals	cUL, UL, CE
EMC filter	Built-in
Communication Options	CANopen, PROFIBUS DP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Output Voltage	0-100% of supply voltage
