Bit
Value = 0 (FALSE)
Value = 1 (TRUE)
Bit 0
Stop request from Fieldbus
Start request from Fieldbus
Bit 1
Forward direction request
Reverse direction request
Bit 2
No action
Reset active faults and alarms (on rising edge 0->1)
Bit 3
No action
Force stop mode to Coasting
Bit 4
No action
Force stop mode to Ramping
Bit 5
No action (normal deceleration ramp
time)
Force drive to use fast deceleration ramp time (1/3 of normal deceleration
time)
Bit 6
No action
Freeze drive frequency reference
Bit 7
No action
Force Fieldbus frequency reference to zero
Bit 8
No action
Force drive control place to Fieldbus control
Bit 9
No action
Force drive reference source to Fieldbus reference
Bit 10
Reserved
Reserved
Bit 11
Reserved
Reserved
Bit 12
No action
Activate Quick Stop function
NOTE! This stops the drive according to setting in parameter menu M3.9.5.
Bit 13
Reserved
Reserved
Bit 14
Reserved
Reserved
Bit 15
Reserved
Reserved
10.11.2 (ID 875) FB Speed Reference
Location in the menu: V2.12.2
This monitoring value shows the fieldbus frequency reference as a percentage of minimum frequency to maximum frequency.
The speed reference information is scaled between the minimum and the maximum frequency at the moment when the applica-
tion received it. The minimum and the maximum frequencies can be changed after the application received the reference without
an effect on the reference.
10.11.3 (ID 876) FB Data IN 1
Location in the menu: V2.12.3
This monitoring value shows the raw value of process data in a 32-bit signed format.
10.11.4 (ID 877) FB Data IN 2
Location in the menu: V2.12.4
This monitoring value shows the raw value of process data in a 32-bit signed format.
10.11.5 (ID 878) FB Data IN 3
Location in the menu: V2.12.5
This monitoring value shows the raw value of process data in a 32-bit signed format.
10.11.6 (ID 879) FB Data IN 4
Location in the menu: V2.12.6
This monitoring value shows the raw value of process data in a 32-bit signed format.
