Table 128: The Selection of Preset Frequencies when Preset Frequency Mode is Binary Coded
Digital input signal Pre-
set Freq Sel2
(P3.3.3.12)
Digital input signal Pre-
set Freq Sel1
(P3.3.3.11)
Digital input signal Pre-
set Freq Sel0
(P3.3.3.10)
Activated frequency reference
Preset frequency 0
Only if Preset Freq 0 is set as frequency refer-
ence source with P3.3.3.1.5, P3.3.1.6, P3.3.1.7 or
P3.3.1.10.
Value 1 selected
It is possible to use the Preset Frequencies 1–3 with different sets of active digital inputs. The number of active inputs tells which
one is used.
Table 129: The Selection of Preset Frequencies when Preset Frequency Mode is Number of Inputs
Digital input signal Pre-
set Freq Sel2
(P3.3.3.12)
Digital input signal Pre-
set Freq Sel1
(P3.3.3.11)
Digital input signal Pre-
set Freq Sel0
(P3.3.3.10)
Activated frequency reference
Preset frequency 0
Only if Preset Freq 0 is set as frequency refer-
ence source with P3.3.3.1.5, P3.3.1.6, P3.3.1.7 or
P3.3.1.10.
11.5.2.2 (ID 180) Preset Frequency 0
Location in the menu: P3.3.3.2
Use this parameter to set the preset frequency reference when the preset frequencies function is used. Select the preset frequencies
with the digital input signals.
See more information in 11.5.2.1 (ID 182) Preset Frequency Mode.
11.5.2.3 (ID 105) Preset Frequency 1
Location in the menu: P3.3.3.3
AB298035655957en-000201 / DPD01083186 | Danfoss A/S © 2023.08
Parameter Descriptions
VACON® 100 FLOW
Application Guide
