e30bg493.10
Illustration 51: The Option Board Slots and Programmable Inputs
A
Standard board slot A and its terminals
B
Standard board slot B and its terminals
C
Option board slot C
D
Option board slot D
E
Option board slot E
F
Programmable digital inputs (DI)
G
Programmable analog inputs (AI)
11.7.1.2 Programming of Digital Inputs
Find the applicable functions for digital inputs as parameters in parameter group M3.5.1. To give a digital input to a function, set a
value to the correct parameter. The list of applicable functions shows in Table 44.
AB298035655957en-000201 / DPD01083194 | Danfoss A/S © 2023.08
Parameter Descriptions
VACON® 100 FLOW
Application Guide
