5.7.6.5 Extended I/O Terminals
Table 37: Auxiliary Function Option Codes
Character po-
sition
Option
code
Description
23–24 A2 Extended I/O terminals
AA AC socket+cabinet light + extended I/O terminals
AE AC socket+cabinet light + extended I/O terminals + cabinet heater
AF AC socket+cabinet light + extended I/O terminals + motor heater control
AG AC socket+cabinet light + extended I/O terminals + insulation monitor
AH AC socket+cabinet light + extended I/O terminals + cabinet heater + motor heater control
AI AC socket+cabinet light + extended I/O terminals + cabinet heater + insulation monitor
AJ AC socket+cabinet light + extended I/O terminals + motor heater control + insulation monitor
AK AC socket+cabinet light + extended I/O terminals + cabinet heater + motor heater control + insula-
tion monitor
AP Extended I/O terminals + cabinet heater
AQ Extended I/O terminals + motor heater control
AR Extended I/O terminals + insulation monitor
AS Extended I/O terminals + cabinet heater + motor heater control
AT Extended I/O terminals + cabinet heater + insulation monitor
AU Extended I/O terminals + cabinet heater + motor heater control + insulation monitor
AV Extended I/O terminals + motor heater control + insulation monitor
The extended I/O terminal option includes 25 control terminals (-XDW) in the control compartment for use by the customer. If the
enclosed drive is configured with any option C1 card, the -XDW terminal block is used for the option C1 card wiring.
