Product Reference Guide 129
Chapter 11
Data Editing
Data Editing Overview
When a barcode is scanned, additional information can be sent to the host computer along with
the barcode data. This combination of barcode data and supplementary user-defined data is
called a “message string.” The features in this chapter can be used to build specific user-defined
data into a message string.
There are several types of selectable data characters that can be sent before and after scanned
data.
You can specify if they should be sent with all symbologies, or only with specific
symbologies. Figure 16 shows the available elements you can add to a message string:
Figure 16. Breakdown of a Message String
Prefix SuffixAIM IDLabel ID Label IDBar Code Data
00 - 20 Characters (ASCII)
Label ID Transmission:
Enable this option to
transmit the Label ID you
configure for the scanned
symbology.
AIM ID: This function is used to identify and display the
common label identifier for its symbology. When enabled,
this ID code will be transmitted before the scanned bar
code data.
OR...
NOTE
CAUTION
It is not recommended to use these features with IBM inter-
faces.
Additional advanced editing is available. See the Advanced formatting
features in the Datalogic Aladdin configuration software, or contact
Technical Support (described on page 11) for more information.
