246 Gryphon™ I GD4100/GM4100

Codablock F

The following options apply to the Codablock F symbology.

Codablock F Enable/Disable

Enables/Disables ability of reader to decode Codablock F labels.

ENTER/EXIT PROGRAMMING MODE

Codablock F = Disable

Codablock F = Enable

DEFAULT

Default Chapter3
