Symbologies

338 Gryphon™ I GD4100/GM4100

Code 93

The following options apply to the Code 93 symbology.

Code 93 Enable/Disable

Enables/Disables ability of reader to decode Code 93 labels.

ENTER/EXIT PROGRAMMING MODE

Code 93 = Disable

Code 93 = Enable

DEFAULT
