Product Reference Guide 73
Chapter 5
RS-232 ONLY Interface
Introduction
Use the programming barcodes in this chapter if modifications to the standard RS-232 interface
settings are necessary to meet your system’s requirements. Additional settings which apply to
both the RS-232 and USB interfaces are available in Chapter 6, RS-232/USB-Com Interfaces.
RS-232 Standard Factory Settings
Reference Appendix C, Standard Defaults for a listing of standard factory settings.
Baud Rate
Baud rate is the number of bits of data transmitted per second. Set the reader's baud rate to
match the baud rate setting of the host device. With an improper baud rate setting, data may
not reach the host correctly.
ENTER/EXIT PROGRAMMING MODE
Baud Rate = 1200
Baud Rate = 2400
Baud Rate = 4800
To Next Page
