Getting Started
16 Gryphon™ I GD4100/GM4100
Install the Batteries
To install or change the battery of your reader, you must:
1. With a screwdriver, unscrew the battery cover screw.
2. Unplug the three screws securing the battery holder, and unplug the white connector.
3. Carefully lift out the gold contacts circuit, and remove the battery holder while letting the
white connector pass through the hole in the battery holder (as shown in the picture
below).
4. Remove the old battery from its place (if present), and insert the new battery in the same
position.
5. Replace the battery holder, plug in the connector and return the contacts circuit to its pre-
vious location.
NOTE
When inserting the new battery into the handle, take care to position the battery
and the connector as shown.
