LED and Beeper Indicators

Product Reference Guide 39

LED and Beeper Indicators

Power On Alert

Disables or enables the indication (from the Beeper) that the reader is receiving power.

ENTER/EXIT PROGRAMMING MODE

Power On Alert = Disable (No Audible Indication)

Power On Alert = Four Beeps

DEFAULT

Default Chapter3
