Symbologies
350
Gryphon™ I GD4100/GM4100
MSI
The following options apply to the MSI symbology.
MSI Enable/Disable
Enables/Disables ability of re
ader to decode MSI labels.
ENTER/EXIT PROGRAMMING MODE
MSI = Disable
MSI = Enable
DEF
A
UL
T
351
