LED and Beeper Indications
Product Reference Guide 389
Base Station Indications
INDICATION LEDS
Power-up Complete Yellow LED on
Reader Disabled by the HOST or the communica-
tion with HOST is not established
Yellow LED blinking ~1Hz
Data/labels are transmitted to the HOST Yellow LEDs turned off for 100mSec
Programming Mode Yellow LED blinks quickly
Base and handheld are exchanging data Red LED blinks quickly
Battery charger in progress Red LED on
Battery charger complete Green LED on
Battery charger error
Green LED and Red LEDs blink alterna-
tively ~1Hz
No handheld is placed on the cradle Red and Green LEDs off
