Product Reference Guide 203

Optional GS1-128 Add-On Timer

This option sets the timer expiration value to read the added part after reading the linear EAN/

UPC part. For UPC/EAN add-ons other than those of that type, see "Optional Add-On

Timer"on page 200.

ENTER/EXIT PROGRAMMING MODE

Optional GS1-128 Add-On Timer = Disable

Optional GS1-128 Add-On Timer = 10ms

Optional GS1-128 Add-On Timer = 20ms

Optional GS1-128 Add-On Timer = 30ms

Optional GS1-128 Add-On Timer = 40ms

Optional GS1-128 Add-On Timer = 50ms

DEFAULT
