Technical Specifications
384 Gryphon™ I GD4100/GM4100
Operating autonomy
(continuous reading)
50,000 reads
(typical)
Performance Characteristics
Light Source Dual LEDs
Roll (Tilt) Tolerance ± 35° from normal
Pitch Tolerance ± 65°
Skew (Yaw) Tolerance ± 65°
Field of View 10” (25.4cm) wide at 12.5” (31.8cm) from the reader
Depth of Field (Typical) (d)
3 mil – 2.9” to 4.7” (7.5cm to 12cm)
13 mil (d) – 1.2” to 23.6” (3cm to 60cm)
20 mil – 1.2” to 31.5” (3cm to 80cm)
Minimum Element Width 3 mil
Print Contrast Minimum 15% minimum reflectance
Decode Capability
UPC/EAN/JAN, P2 /P5, ISBN/ISSN; Co
de 39, Code39 FullASCII;
Italian Pharmacode 39, Code39 CIP; Code 128, GS1-128; C128
ISBT; Code 128 addons;I 2 of 5; Standard 2 of 5; I 2 of 5 CIP HR;
Industrial 2 of 5; IATA; Datalogic 2 of 5; Follet 2 of 5; Code 11;
Plessey, Anker Plessey; Codabar, ABC Codabar ; Code 93; MSI;
GS1 DataBar™ Omnidirectional, GS1 DataBar™ Limited, GS1
DataBar™ Expanded; Code 4, Code 5; Codablock F, Codablock
F EAN;
Interfaces Supported(b)
RS-232 Std, RS-232 Wincor-Nix
dor
f, RS-232 OPOS, IBM 46xx
(ports 5B and 9B), USB Com Std., USB Keyboard, USB Alternate
Keyboard,USB OEM, Keyboard Wedge (AT with or w/o Alter-
nate Key, IBM AT PS2 with or w/o Alternate Key, PC-XT, IBM
3
153
, IBM Terminals 31xx, 32xx,34xx, 37xx make only and
make break keyboard, Digital Terminals VT2x, VT3xx, VT4xx,
and Apple) and Wand Emulation.
User Environment
Operating Temperature 32° to 131° F (0° to 55° C)
Charging Temperature 32° to 104° F (0° to 40° C)
Storage Temperature -4° to 158° F (-20° to 70° C)
Humidity Operating: 5% to 90% relative humidity, non-condensing
Drop Specifications 18 drops from 1.8 meters (5.9 feet) to concrete
Ambient Light Immunity Up to 100,000 Lux
Contaminants Spray/rain-
Dust/particulates
GD41x0 IP52
GM4100 IP42
ESD Level 16 KV
