Enter/Exit Programming Mode Disable All Symbologies
90 QuickScan™ I QD21X1 / QM21X1 / QBT21X1
Disable All Symbologies
Scan this label to disable all symbologies.
Disable all symbologies
Coupon Control
This feature is used to control the method of processing coupon labels.
Options are:
• Allow all — allow all coupon
bar codes to be decoded
• Enable only UPC/EAN — enables only UPC/EAN coupon decoding
• Enable only GS1 DataBar — enables only GS1 DataBar coupon decoding
To set this feature:
1. Scan the Enter/Exit bar
code.
2. Scan either the enable or disable bar code below. You’ll need to cover any
unused bar codes on this and the facing page to ensure that the reader
sees only the bar code you intend to scan.
3. Complete the programming sequence by scanning the Enter/Exit bar code.
$AD
$CCPCL00
Coupon Control = Allow all
$CCPCL01
Coupon Control = Enable only UPC/EAN
$CCPCL02
Coupon Control = Enable only GS1 DataBar
To Next Page
