To Next Page

To Previous Page

Enter/Exit Programming Mode Code 93

230 QuickScan™ I QD21X1 / QM21X1 / QBT21X1

Code 93 Stitching

Disable/enable fixed or variable length stitching for Code 93.

Code 93 Stitching = Disable

Code 93 Stitching = Enable

Code 93 Character Correlation

Enables/disables Character Correlation for Code 93.

Code 93 Character Correlation = Disable

Code 93 Character Correlation = Enable

$CC9ST00

$CC9ST01

DEFAULT

$CC9CO00

$CC9CO01

DEFAULT
