310 QuickScan™ I QD21X1 / QM21X1 / QBT21X1
BT-Only Features
BT Pin Code
This option specifies the 4-character or 16-character pin code to be used for
authentication of the BT link. To set the pin code:
1. Scan the E
NTER/EXIT PROGRAMMING MODE bar code to enter Program-
ming Mode, then enable
"BT Security Mode"
on page 269.
2. Specify the desired pin code length (4 or 16) by scanning the appropriate
bar code in
"Select PIN Code Length"
on page 270.
3. Determine the desired characters. For example, D254 or
pql oNOPQRS TUNPRj
4. Convert the characters to hexadecimal using the
ASCII Chart
on the inside
back cover of this manual.
5. Go to
page 270
and Scan the bar code: SET 4 CHAR PIN CODE or SET 16-
CHAR PIN CODE.
6. Scan the appropriate alphanumeric characters from the keypad in
Appendix
D, Keypad
, representing the hexadecimal entries determined in the steps
above. You will hear a two-beep indication after the last character.
7. Scan the ENTER/EXIT PROGRAMMING MODE bar code to exit Programming
Mode.
This completes the procedure. See
Table 26
for some examples of how to set
this feature.
Table 26. BT Pin Code Setting Examples
STEP ACTION EXAMPLES
1 Desired Setting
D254 STOR12345678135M
2
Convert the characters to
hexa
decimal
44 32 35 34 53 54 4F 52 31 32 33 34 35 36 37 38 31 33 35 4D
3 Scan ENTER/EXIT PROGRAMMING MODE
4 Scan SET BT PIN CODE
5
Scan 8 or 32
Alph
anumeric Characters
From
Appendix D,
Keypad
44323534 53544F5231323334353637383133354D
6 Scan ENTER/EXIT PROGRAMMING MODE
NOTE
If you make a mistake before the last character, scan the CANCEL bar code to abort and not
save the entry string. You can then start again at the beginning.
NOTE
Changing the pin code setting will unlink the devices. If the Automatic Configuration Update
is set to the default enabled setting, the devices must only be relinked. If the Automatic Con-
figuration Update is set to the disabled setting, the Pin Code setting must also be updated in
the Base Station using Aladdin. After the Base Station has been updated, the devices must be
relinked.
