To Next Page

To Previous Page

Symbologies Enter/Exit Programming Mode

Product Reference Guide

199

Code 11 Decoding Level

Decoding Levels are used to configure a bar code symbology decoder to be very

aggressive to very conservative depending on a particular customer’s needs.

See "Decoding Levels" on page 305 for more detailed programming instruc-

tions.

Code 11 Decoding Level = 1

Code 11 Decoding Level = 2

Code 11 Decoding Level = 3

Code 11 Decoding Level = 4

Code 11 Decoding Level = 5

$CC1DL01

$CC1DL02

$CC1DL03

$CC1DL04

$CC1DL05

DEFAULT
