176 QuickScan™ I QD21X1 / QM21X1 / QBT21X1

Codabar

Codabar Enable/Disable

When disabled, the reader will not read Codabar bar codes.

Codabar = Disable

Codabar = Enable

$CCBEN00

$CCBEN01

DEFAULT
