14 QuickScan™ I QD21X1 / QM21X1 / QBT21X1
Charging the Battery Pack
To charge the battery, simply insert the QuickScan reader into the base. When
the scanner is fully seated in the cradle, it will sound a “chirp” to indicate that
the cradle has detected the scanner connection.
The LEDs on the base (shown in
Table 1 on page 13
) will indicate the status of the
battery.
NOTE
Before using the battery, read “Battery Safety” in
the following section. Datalogic rec-
ommends annual replacement of rechargeabl
e battery packs to ensure maximum per-
formance.
Alternatively, the battery can be charged by connecting the reader directly to a
host or a wall adapter through the micro-USB connector in the bottom of the
handle, as shown.
