26 QuickScan™ I QD21X1 / QM21X1 / QBT21X1
Configuration Parameters
Once the reader is set up, you can change the default parameters to meet your
application needs. Refer to
"Standard Defaults" starting on page 317 for initial
configuration in order to set the default values and select the interface for your
application.
The following configuration parameters are divided into logical groups, making
it easy to find the desired function based on its reference group.
Interface-Specific Parameters:
• "RS-232 ONLY Interface" on page 29
• “RS-232, USB-COM and Keyboard, BT HID Interfaces” on page 34
• "Keyboard Interface" on page 45
• "USB-OEM Interface" on page 57
Parameters common to all interface applications:
• "Data Format" on page 59 control various operating modes and indicators
status functioning.
• "Reading Parameters" on page 73 gives options to control the messages
sent to the Host system.
Symbology-specific parameters:
• "Symbologies" on page 89 provides configuration of a personalized mix of
1D codes, code families and their options.
To program features:
1. Scan the ENTER/EXIT PROGRAMMING bar code, available at the top of each
programming page, when applicable.
2. Scan the bar code to set the desired programming feature. You may need
to cover unused bar codes on the page, and possibly the facing page, to
ensure that the reader reads only the bar code you intend to scan.
3. If additional input parameters are needed, go to Appendix D, Keypad, and
scan the appropriate characters from the keypad.
4. Complete the programming sequence by scanning the ENTER/EXIT PRO-
GRAMMING bar code to exit Programming Mode.
For more detailed descriptions, programming information and examples for
setting selected configuration items, see
References, starting on page 279.
NOTE
You must first enable your reader to read bar codes in order to use this section. If you have not
done this, go to
Setup, starting on page 3
and complete the appropriate procedure.
NOTE
Additional information about many features can be found in the “References” chapter.
If you make a mistake before the last character, scan the CANCEL bar code to abort and not save
the entry string. You can then start again at the beginning.
