Locking the Reader to the Base
The Base Station provides a locking mechanism to ensure electrical contact
between Reader and Base, in case of inadvertent movements.
Lock
Lever
To Lock the Reader in the Base
1. Insert the Reader into the Base. The lock lever rests in its natural disen-
gaged position toward the bottom of the Base.
Figure 5. Lock lever disengaged
