Enter/Exit Programming Mode GS1 DataBar
TM
Expanded
130 QuickScan™ I QD21X1 / QM21X1 / QBT21X1
GS1 DataBar Expanded Set Length 2
This feature specifies one of the bar code lengths for GS1 DataBar Expanded
Length Control on page 128. Length 2 is the maximum label length if in Vari-
able Length on page 128 Mode, or the second fixed length if in Fixed Length on
page 128 Mode. Length includes the bar
code’s data characters only.
The length can be set from 1 to 74 characters. A setting of 00 specifies to
ignore this length (only one fixed length). See "Set Length 2" on
page 307 for
more detailed programming instructions.
Select GS1 DataBar Expanded Set Length 2 Setting
Make a mistake? Scan the CANCEL bar code to abort and
not save the entry string. You can then start again at the
beginning.
CANCEL
$CXBL2
~
DEFAULT
74 = Length 2 is 74 Characters
To Next Page
