144 QuickScan™ I QD21X1 / QM21X1 / QBT21X1

Code 39 Interdigit Ratio (continued)

$CC3IR06

Code 39 Interdigit Ratio = 6

$CC3IR07

Code 39 Interdigit Ratio = 7

$CC3IR08

Code 39 Interdigit Ratio = 8

$CC3IR09

Code 39 Interdigit Ratio = 9

$CC3IR0A

Code 39 Interdigit Ratio = 10
