Datalogic QuickScan I QD21 1 Series

To Next Page

To Previous Page

Symbologies Enter/Exit Programming Mode

Product Reference Guide

187

Codabar Interdigit Ratio (continued)

$CCBIR06

Codabar Interdigit Ratio = 6

$CCBIR07

Codabar Interdigit Ratio = 7

$CCBIR08

Codabar Interdigit Ratio = 8

$CCBIR09

Codabar Interdigit Ratio = 9

$CCBIR0A

Codabar Interdigit Ratio = 10
