12 QuickScan™ I QD21X1 / QM21X1 / QBT21X1
Linking to a PC in HID mode
NOTE
Once the reader has been connected using HID mode directly to an Apple® iPad,
smart phone, or laptop, you can toggle the
virtual keyboard on the host with double
press trigger within 0,5 second. This feature is only supported with Apple devices.
1. Install any drivers provided with the Bluetooth adapter.
2. Scan the
Link to PC in HID
label below.
3. Use the host computer’s Bluetooth manager to “Discover new devices” and
select “Datalogic Scanner.” If you receive an error message, it may be nec-
essary to disable security on the device.
4. Use a text editor to see incoming data on the port designated by the com-
puter's Bluetooth manager.
Power Off
Shuts off power to the BT handheld until the next trigger pull. This function
only applies to the BT model.
