296 QuickScan™ I QD21X1 / QM21X1 / QBT21X1
Label ID: Set Individually Per Symbology — continued
Table 16
STEP ACTION EXAMPLES
1. Scan the ENTER/EXIT bar code
(Reader enters Programming Mode)
2.
Determine placement of the
L
abel ID characters BEFORE or
AFTER with regard to scanned
data using
"Label ID Control"
on page 63
Enable as Prefix Enable as Suffix Enable as Prefix Enable as Suffix
3.
Scan the bar code selecting the
sym
bology type you wish to
designate label ID characters
for using
Label ID Symbology
Selection, starting on page
64
.
GS1 DataBar
Omnidirectional
Code 39 Interleaved 2 of 5 Code 32
4.
Custom Label ID example
(desired characters):
D B * = C 3 + P H
5.
Find hex equivalents from the
ASCI
I table (inside back cover),
then scan in these digits/
characters using the bar codes
in the section:
Keypad, starting on page
335
. f you make a mistake
before the last character, scan
the CANCEL bar code to abort
and not save the entry string.
You can then start again at the
beginning.
44 42 2A 3D 43 33 2B 50 48
6. Scan theENTER/EXIT bar code
(Reader exits Label ID entry)
7.
Scan the ENTER/EXIT bar code
onc
e again
(Reader exits Programming Mode)
Result:
DB*[bar code
data]
[bar code
data]=C3
+[bar code data] [bar code data]PH
. Label ID Examples
