Item QD2131 QM/QBT21X1
Performance Characteristics
Light Source LEDs
Roll (Tilt) Angle
a
Up to 45° Up to ± 45°
Pitch Angle
a
± 65°
Skew (Yaw) Angle
a
70°
Field of View 56 ± 2°
Field of View
Code 39
5 mils: 0.8’’ - 7’’ (2 - 18 cm)
7.5 mils: 0.8’’ - 12’’ (2 - 30 cm)
10 mils: 0.8’’ - 17’’ (2 - 44 cm)
20 mils: up to 29.5’’ (75 cm)
EAN
13 mils: 0.8” - 23” (2 - 58 cm)
Code 39
5 mils: 0.8 to 5.9''(2.0 to 15 cm)
7.5 mils: 0.8 to 9.8'' (2.0 to 25 cm)
10 mils: 0.8 to 14.2'' (2.0 to 36 cm)
20 mils: up to 27.5'' (up to 70 cm )
EAN
13 mils 0.4 to 17.7'' (1.0 to 45 cm)
Depth of Field (Typical)
b
Minimum Element Width 4 mils - 0,01 cm
Print Contrast Minimum 25% minimum reflectance
312 QuickScan™ I QD21X1 / QM21X1 / QBT21X1
a.
Based on ISO 15423 specifications
b.
13 mils DOF based on EAN. All other codes are Code 39. All labels grade A, typical environmental light, 20°C, label
inclination 10°
Item QD2131 QM/QBT21X1
Decode Capability
UPC/EAN/JAN (A, E, 13, 8); UPC/EAN/JAN (including P2 /P5); UPC/EAN/JAN (including; ISBN /
Bookland & ISSN); UPC/EAN Coupons; Code 39 (including full ASCII); Code 39 Trioptic; Code39
CIP (French Pharmaceutical); LOGMARS (Code 39 w/ standard check digit enabled); Danish
PPT; Code 32 (Italian Pharmacode 39); Code 128; Code 128 ISBT; Interleaved 2 of 5; Standard 2
of 5; Interleaved 2 of 5 CIP (HR); Industrial 2 of 5; Datalogic 2 of 5 (China Post Code/Chinese 2
of 5); IATA 2of5 Air cargo code; Code 11; Codabar; Codabar (NW7); ABC Codabar; Code 93; MSI;
PZN; Plessey; Anker Plessey; Follet 2 of 5; GS1 DataBar Omnidirectional; GS1 DataBar Limited;
GS1 DataBar Expanded; GS1 DataBar Truncated; DATABAR Expanded Coupon.
Interfaces Supported
RS-232 Std, RS-232 Wincor-Nixdorf, RS-232 OPOS, USB Com Std., USB Keyboard, USB Alter-
nate Keyboard, USB OEM, Keyboard Wedge (AT with or w/o
Alternate Key, IBM AT PS2 with or
w/o Alternate Key, USB Composite (keyboard + COM).
