Chapter 2 Mechanical Installation｜VP3000
8
Minimum mounting clearance
Frame
A (mm)
B (mm)
A–C
60
30
D–I
100
50
J
200
100
K
200
100
L
350
100
M
350
100
NOTE: The minimum mounting clearances A–B stated in the table above apply to AC motor drives
installation. Failing to follow the minimum mounting clearances may cause the fan to malfunction and
heat dissipation problems.
Table 2-1
Frame A
VFD3A0VP43ANTAA; VFD4A2VP43ANTAA; VFD5A6VP43ANTAA; VFD7A2VP43ANTAA;
VFD011VP43ANTAA; VFD013VP43ANTAA; VFD018VP43ANTAA; VFD025VP43ANTAA;
VFD032VP43ANTAA; VFD038VP43ANTAA; VFD3A0VP43BFTAA; VFD4A2VP43BFTAA;
VFD5A6VP43BFTAA; VFD7A2VP43BFTAA; VFD011VP43BFTAA; VFD013VP43BFTAA;
VFD018VP43BFTAA; VFD025VP43BFTAA; VFD032VP43BFTAA; VFD038VP43BFTAA
Frame B
VFD013VP43ANTAA; VFD018VP43ANTAA; VFD013VP43BFTAA; VFD018VP43BFTAA
Frame C
VFD025VP43ANTAA; VFD032VP43ANTAA; VFD038VP43ANTAA
VFD025VP43BFTAA; VFD032VP43BFTAA; VFD038VP43BFTAA
Frame D
VFD045VP43ANTCA; VFD062VP43ANTCA; VFD045VP43BFTCA; VFD062VP43BFTCA;
VFD045VP43BSTCA; VFD062VP43BSTCA
Frame E
VFD073VP43ANTCA; VFD090VP43ANTCA; VFD073VP43BFTCA; VFD090VP43BFTCA;
VFD073VP43BSTCA; VFD090VP43BSTCA
Frame F
VFD110VP43AFTCA; VFD110VP43BFTCA; VFD110VP43BSTCA
Frame G
VFD150CP43AFTCA; VFD150VP43BFTCA; VFD150VP43BSTCA
Frame H
VFD180VP43AFTCA; VFD220VP43AFTCA; VFD180VP43BFTCA; VFD220VP43BFTCA;
VFD180VP43BSTCA; VFD220VP43BSTCA
Frame I
VFD260VP43AFTCA; VFD310VP43AFTCA; VFD260VP43BFTCA; VFD310VP43BFTCA;
VFD260VP43BSTCA; VFD310VP43BSTCA
Frame J
VFD370VP43AFTCA; VFD395VP43AFTCA; VFD370VP43BFTCA; VFD395VP43BFTCA;
VFD370VP43BSTCA; VFD395VP43BSTCA
Frame K
VFD460VP43AFTCA; VFD485VP43AFTCA; VFD460VP43BFTCA; VFD485VP43BFTCA;
VFD460VP43BSTCA; VFD485VP43BSTCA
Frame L
VFD530VP43SHTCA; VFD616VP43SHTCA; VFD683VP43SHTCA; VFD770VP43SHTCA
Frame M
VFD866VP43SHTCA; VFD930VP43SHTCA; VFD1K1VP43SHTCA; VFD1K2VP43SHTCA
Table 2-2
