Chapter 11 Specification | VP3000
695
11-2-2 Environment for Operation, Storage and Transportation
Do NOT expose the AC motor drive in the bad environment, such as dust, direct sunlight, corrosive/ inflammable gasses,
humidity, liquid, and vibration environment. The salt in the air must be less than 0.01 mg/ cm
2
every year.
IEC60364-1/ IEC60664-1 Pollution degree 2, Indoor use only
Surrounding
Temperature
(oC)
Non-condensation, non-conductive pollution
IEC60721-3-3 Class 3C3; Class 3S2
IEC60721-3-1 Class 1C2; Class 1S2
IEC60721-3-2 Class 2C2; Class 2S2
If you use the AC motor drive under harsh environment with high level of contamination
(e.g., dew, water, dust), make sure it is installed in an environment qualified for IP54
such as in a cabinet.
If the AC motor drive is installed at an altitude 0–1000 m, follow normal
operation restriction. For it is installed at altitude over 1,000 m,
decrease 1% of rated current or lower 0.5°C of temperature for every
100 m increase in altitude. Maximum altitude for Corner Grounded TN
system is 2,000 m.
Maximum altitude for 480 V
AC
input voltage is 2,000 m.
Maximum altitude for 380 V
AC
input voltage is 4,000 m.
ISTA procedure 1A (according to weight) IEC60068-2-31
Frame A–K: 1.0 mm, peak to peak value range from 2 Hz to 13.2 Hz: 0.7–1.0G range from 13.2 Hz to 55
Hz: 1.0G range from 55 Hz to 512 Hz. Comply with IEC 60068-2-6
Frame L, M Chassis: 1.0 mm, peak to peak value range from 2 Hz to 13.2 Hz; 0.7G range from 13.2 Hz to
100 Hz
Max. allowed offset angle ±10% (under normal installation
position)
10 10
