Chapter 5 Initial Operation and Adjustment | VP3000
214
5-3 Start Process
The following are abbreviations for different types of motors:
⚫ IM: Induction motor
⚫ SM: Synchronous AC motor
⚫ PM: Permanent magnet synchronous AC motor
⚫ IPM: Interior permanent magnet synchronous AC motor
⚫ SPM: Surface permanent magnet synchronous AC motor
⚫ PMA: Permanent magnet assisted synchronous reluctance motor
⚫ SynRM: Synchronous reluctance motor
5-3-1 Parameter Setting
5-3-1-1 Adjustment Flowchart
Start
Parameter Reset b0-01
9: Reset 50Hz default
10: Reset 60Hz default
EX1 OPER Cmd Src A1-01
EX1 Main FREQ Src C1-01
Motor Parameter
Autotune
B-0
SM
A-0
IM
0: Disable
1: Keypad
2: RS-485
3: USB
4: COM Card
7–9: AI1–AI3
12–13: AI10–AI11
16: Up/down keys
17: Pulse Train
18: PID
0: Disable
1: S1 Start
2: S1 Start, S2 Dir
3: S1 FWD, S2 REV
4: S1 Start, S2 Stop
5: S1 Start, S2 Stop, S3 Dir
6: S1 FWD, S2 REV, S3 Stop
7: Keypad
8: RS-485
9: USB
10: EX. COM
