Chapter 6 Drive Communication Network｜VP3000
266
Display output power angle of U, V, W
Display actual output power of U, V, W
Display the IGBT temperature
Display the temperature of capacitance
Display real carrier frequency of the drive
Display overload condition
Display GND fail detect level
Display DC bus voltage ripples
UNITS_REVOLUTIO
NS_PER_MINUTE
Corresponding CPU pin status of digital
input
Corresponding CPU pin status of digital
output
6-2-4-2 BinaryValue (BV) Object
âš« Commandable BinaryValue (BV) Object
In VP3000, BV_000–BV_002 support the commandable Present_Value property. Meanwhile,
these objects also support Priority_Array and Relinquish_Default properties. Therefore, we
can use (multiple) Read_Serivce to access the data.
Run/Stop Cmd
Inactive (0): FreqCmd = 0
Active (1): FreqCmd = FreqRefValue
Fwd/Rev Cmd
Inactive (0): Forward
Active (1): Reverse
Reset Cmd
Inactive (0): Do nothing
Active (1): Reset Fault
