7-1-2 Device communication address of PLC
Device Range of use Type Address (Hex)
X 00–37 (Octal) bit 0400–041F
Y 00–37 (Octal) bit 0500–051F
T 00–159 bit / word 0600–069F
M 000–999 bit 0800–0BE7
M 1000–1359 bit 0BE8–0D4F
C 0–79 bit / word 0E00–0E47
D 0–499 word 1000–11F3
D 1000–1619 word 13E8–1653
D 3000–3999 word 1BB8–1F9F
The available command codes
Command code Function Device
01 Read the status of Coil Y, M, T, C
02 Read the status of input X, Y, M, T, C
03 Read one piece of data T, C, D
05 Force to change the status of one Coil Y, M, T, C
06 Write one piece of data T, C, D
0F Force to change the status of multiple Coil Y, M, T, C
10 Write multiple pieces of data T, C, D
NOTE: When the built-in PLC function of VP3000 is activated, Modbus can visit the device information of
built-in PLC and parameters of AC motor drive at the same time by the different addresses (default: AC
motor drive is 1, built-in PLC is 2).
