Delta VP3000 Series User Manual

Chapter 9 Maintenance and Inspections | VP3000
610
9-2 Fan Kit
Frame A & B
Heat Sink Fan Model: MKVP-AFKM / MKVP-BFKM
1. Use a flathead screwdriver to insert into the groove of the middle cover, and then press the tab
on both sides of the fan to remove it.
Figure 9-1
2. Disconnect the power terminal before removing the fan (as shown below).
Figure 9-2
