Delta VP3000 Series User Manual

Chapter 11 Specification | VP3000
694
11-2 General Specifications
11-2-1 General Features
Control Characteristics
Control Mode
PWM control
Control Method
1: V/F, 2: SVC, 3: PM Sensorless, 4: SynRM Sensorless
Starting Torque
Reach up to 150% or above at 0.5 Hz
V/F Curve
4-point adjustable V/F curve and square curve
Speed Response Ability
IMVF, IMSVC: 1:50
IMFOC Sensorless: 1:100
PMSVC: 1:20
PMFOC Sensorless: 1:50
Torque Limit
In FOC mode, torque quadrants can be set separately via parameters
Torque Accuracy
5%
Max. Output Frequency
(Hz)
599.00 Hz
Frequency Output
Accuracy
Digital command: 0.01%, -10°C – +40°C
Analog command: 0.1%, 25 10°C
Output Frequency
Resolution
Digital command: 0.01 Hz
Analog command: 0.03 × max. output frequency / 60 Hz (11-bit)
Overload Tolerance
Rated output current is 110%: 1 minute for every 5 minutes
Frequency Setting
Signal
0–10 V, 4–20 mA, 0–20 mA
Accel. / Decel. Time
0.00–600.00/ 0.0–6000.0 sec.
Main Control Function
Momentary power loss ride thru, Speed search, Over-torque detection, Torque limit, 16-
step speed (Max.), Accel. / Decel. time switch, S-curve accel. / decel., Three-wire
sequence, Auto-Tuning, Dwell, Slip compensation, Torque compensation, JOG frequency,
Frequency upper/ lower limit settings, DC injection braking at start/ stop, High slip braking,
Energy saving control, Modbus communication (RS-485 RJ45, max. 115.2 Kbps)
Fan Control
Frame A–F: ON/ OFF switch control
Frame G and above: PWM control
Protection Characteristics
Motor Protection
Electronic thermal relay protection
Over-Current Protection
Over-current protection for 195% rated current
Over-Voltage Protection
460V models: drive stops running when DC bus voltage exceeds 820 V
Over-Temperature
Protection
Built-in temperature sensor
Stall Prevention
Stall prevention during acceleration, deceleration, and running independently
Restart after
Instantaneous Power
Failure
Parameter setting up to 20 seconds
Grounding Leakage
Current Protection
Leakage current is higher than 50% of rated current of the AC motor drive
Certifications
Low Voltage Directive (LVD) 2014/35/EU, EN61800-5-1
EMC Directive 2014/30/EU, EN61800-3
UL61800-5-1/ CSA C22.2 No.274
WEEE 2012/19/EU, RoHs 2011/65/EU, 2015/863/EC
Quality assurance system ISO9001 and Environmental system ISO 14001
STO
Safe Torque Off (STO per EN/ IEC61800-5-2)
TUV Rheinland certification
IEC62061/ IEC61508, SIL CL3
EN ISO13849-1, Cat.3/PL d
Table 9-2
NOTE:
1. The maximum output frequency setting range varies with different carrier and control modes.
2. According to the motor protection requirements, you can use the drive internal parameters to adjust the protection level.
