Chapter 2 Mechanical Installation｜VP3000
12
Frame G (Carton, applied for Frame A–G)
Frame L & M (Crate)
Step 3: Unpacking is completed.
Figure 2-12
Step 3: Loosen the screws and fix plates on
both sides of the drive.
Figure 2-13
Step 4: Unpacking is completed.
Figure 2-14
