Chapter 2 Mechanical Installation｜VP3000
15
Frame I1
Applicable models:
VFD260VP43AFTCA; VFD310VP43AFTCA
Frame I2
Applicable models:
VFD260VP43BFTCA; VFD260VP43BSTCA
VFD310VP43BFTCA; VFD310VP43BSTCA
Figure 2-23
Figure 2-24
Frame J1
Applicable models:
VFD370VP43AFTCA; VFD395VP43AFTCA
Frame J2
Applicable models:
VFD370VP43BFTCA; VFD395VP43BFTCA;
VFD370VP43BSTCA; VFD395VP43BSTCA
Figure 2-25
