Deprag AST40-1 User Manual

28
FC_CycleDone BOOL
Cycle ended for F-Function
This signal is currently not available yet!
FC_LockPart BOOL
Lock part for F-Function
This signal is currently not available yet!
DataAvailable BOOL
Data is available
This signal indicates that new screw data is available.
This is reset by the AST40 sequence controller, if the
signal “Data Saved” is set by the SPS program or a new
screwdriving sequence is started.
Error BOOL
Error
This signal indicates that an error has occurred in the FB13
module. The detailed error code is given in the "ErrorCode"
parameter.
HW_FC_ErrReset BOOL
Error Reset for F-Function (hardware interface)
This signal indicates the status of the Reset signal at the
hardware interface.
(see 6.2.7
I/O interfaces)
HW_FC_PartSensor BOOL
Parts sensor for F-function (hardware interface)
This signal indicates the status of the “Parts sensor” signal
at the hardware interface.
(see 6.2.7
I/O interfaces)
HW_FC_ReleasePart BOOL
Part release for F-Function (hardware interface)
This signal indicates the status of the “Part release” signal
at the hardware interface.
(see 6.2.7
I/O interfaces)
HW_ReleaseStart BOOL
Clearance to start (hardware interface)
This signal indicates the status of the “Start approval”
signal at the hardware interface.
(see 6.2.7
I/O interfaces)
HW_Start BOOL
Start signal (Hardware interface)
This signal indicates the status of the start signal at the
hardware interface.
(see 6.2.7
I/O interfaces)
HW_Reload BOOL
Reload signal (hardware interface)
This signal indicates the status of the Reload signal at the
hardware interface.
(see 6.2.7
I/O interfaces)
HW_ProgIn1 BOOL
Input 1 for the screwdriver program (Hardware
interface)
This signal indicates the status of input 1 at the hardware
interface.
(see 6.2.7
I/O interfaces)
HW_ProgIn2 BOOL
Input 2 for the screwdriver program (Hardware
interface)
This signal indicates the status of input 2 at the hardware
interface.
(see 6.2.7
I/O interfaces)
HW_ProgIn3 BOOL
Input 3 for the screwdriver program (Hardware
interface)
This signal indicates the status of input 3 at the hardware
interface.
(see 6.2.7
I/O interfaces)
HW_ProgIn4 BOOL
Input 4 for the screwdriver program (Hardware
