32
fd_Torque2 REAL
Torque value of the Data backup
(2)
The torque value of the data backup (2) is output here
fd_minAngle2 DINT
Lower angle of rotation limit of the Data backup
(2)
The set lower limit of the angle of rotation of the data backup
(2) is output here.
fd_tarAngle2 DINT
Angle of rotation setpoint of the Data backup
(2)
The set angle of rotation setpoint of the data backup (2) is
output here.
fd_maxAngle2 DINT
Upper limit of angle of rotation of the Data backup
(2)
The set upper limit of the angle of rotation of the data backup
(2) is output here.
fd_Angle2 DINT
Angle of rotation value of the Data backup
(2)
The angle value of the data backup (2) is output here
fd_Step3 DINT
Data backup
step number (3)
The step number for the AST40 – program in which a data
backup (3) occurred is output here
fd_minTorque3 REAL
Upper torque limit of the Data backup
(3)
The set lower limit of the angle of rotation of the data backup
(3) is output here.
fd_tarTorque3 REAL
Torque setpoint of the Data backup
(3)
The set lower torque setpoint of the data backup (3) is output
here.
fd_maxTorque3 REAL
Upper torque limit of the Data backup
(3)
The set upper torque limit of the data backup (3) is output
here
fd_Torque3 REAL
Torque value of the Data backup
(3)
The torque value of the data backup (3) is output here
fd_minAngle3 DINT
Lower angle of rotation limit of the
Data backup (3)
The set lower limit of the angle of rotation of the data backup
(3) is output here.
fd_tarAngle3 DINT
Angle of rotation setpoint of the Data backup
(3)
The set angle of rotation setpoint of the data backup (3) is
output here.
fd_maxAngle3 DINT
Upper limit of angle of rotation of the Data backup
(3)
The set upper limit of the angle of rotation of the data backup
(3) is output here.
fd_Angle3 DINT
Angle of rotation value of the Data backup
(3)
The angle value of the data backup (3) is output here
fd_StepNOk DINT
Step number of the Data backup
for a faulty screw
assembly
The step number for the AST40 – program in which the data
on a faulty screw assembly was backed up is output here
fd_minTorqueNOk REAL
Lower torque limit for a faulty screw assembly
The set upper limit of the torque for a faulty screw assembly
is output here.
fd_tarTorqueNOk REAL
Torque setpoint for a faulty screw assembly
The set torque setpoint of the faulty screw assembly (1) is
output here.
fd_maxTorqueNOk REAL
Upper torque limit for a faulty screw assembly
The set upper limit of the torque for a faulty screw assembly
is output here.
