Control 24 Reference Guide26
Footswitch
The SW 1 and SW 2 jacks can be assigned to any
of three available Footswitch functions:
• Play/stop
• Record (punch-in/punch out)
• Remote TALKBACK on/off
Both footswitch inputs’ polarity is selectable to
support virtually any available momentary foot-
switch.
The function and polarity of the footswitch
jacks SW 1 and SW 2 are configured using the
Control 24 UTILITY menus. Press UTILITY >
GPIs > SWITCH 1 (or SWITCH 2) and configure
the polarity and functions. (See Appendix B,
“Utility Functions” for more information on
UTILITY.)
Control_24.book Page 26 Wednesday, January 17, 2001 2:51 AM

DigiDesign Control 24 Specifications

General

Channels	24
Faders	24 motorized 100mm faders
Connectivity	Ethernet
Compatibility	Pro Tools
Audio Interface	No built-in audio interface
EQ	4-band EQ per channel
MIDI I/O	Yes
Footswitch I/O	Yes
Power Supply	Internal
