Control 24 Reference Guide60
Meter Select Options
The upper left of Control 24 contains five but-
tons. With these buttons you can choose differ-
ent modes for the twenty-four pairs of channel
strip meters.
Each of the 24 channels on Control 24 includes
a dual, 14 segment meter display. During nor-
mal operation, these meters will display the
post-fader output levels of the Pro Tools chan-
nels they represent. Only the left side will re-
spond to mono tracks.
With the Demo Session playing, try switching to
PRE FADER, that will cause most of the meters to
rise to their actual levels, unattenuated by the
faders. The red peak indicators at the top of the
meters can be reset by pressing the CLEAR
PEAKS button.
Window Section
Eight WINDOW buttons toggle their corre-
sponding Pro Tools window open or close:
• MIX
• EDIT
• STATUS: Session Setup
• TRANS: Transport
• PLUG-IN:
• MEM-LOC: Memory Locations
•PAN
• ALT (not used)
Window Options
You can use the eight window selection buttons
(located above the NAV and ZOOM buttons and
arrows) for quick navigation to each of the pri-
mary on-screen display modes.
The STATUS, TRANS, and MEM-LOC buttons
open or close the Session Setup, Transport, and
Memory Location windows, respectively.
The PLUG IN button toggles the window of the
last (if any) plug-in accessed open or closed.
To close all plug-in windows:
■ Press OPT(ALT)/ALL+PLUG IN.
To close all Pan and Send windows:
Press OPT(ALT)/ALL+PAN.
Control_24.book Page 60 Wednesday, January 17, 2001 2:51 AM
