Configuration
Vertical tab "Waveforms"
Vertical tab "Colors"
Headline/
Parameter
Setting range
Description
Sweep speed
[mm/s]
6.25; 12.5; 25 6.25; 12.5; 25 6.25; 12.5; 25 Specify sweep speed.
VT scale
[mL]
Auto;
0 to 10;
0 to 50;
0 to 150;
0 to 500;
0 to 1000;
0 to 2000
Auto;
0 to 10;
0 to 50;
0 to 150;
0 to 500;
0 to 1000;
0 to 2000
Auto;
0 to 10;
0 to 50;
0 to 150;
0 to 500;
0 to 1000;
0 to 2000
Specify scale for volumeter.
Flow scale
[L/min]
Auto
-5 to 5
-10 to 10;
-30 to 30;
-60 to 60;
-120 to 120
Auto
-5 to 5
-10 to 10;
-30 to 30;
-60 to 60;
-120 to 120
Auto
-5 to 5
-10 to 10;
-30 to 30;
-60 to 60;
-120 to 120
Specify scale for flow waveform.
O
2 scale
[%]
Auto;
0 to 100; 15 to 35; 25 to 45; 35 to 55;
45 to 65; 55 to 75; 65 to 85; 75 to 95;
85 to 105
Specify scale for O2 waveform.
CO2 scale [%]; [kPa]: Auto; 0 to 6; 0 to 12
[mmHg]: Auto; 0 to 50; 0 to 100
Specify scale for CO2 waveform.
Paw scale
[mbar]; [hPa];
[cmH
2O]
Auto; -5 to 20; -7.5 to 30; -10 to 40; -20 to 80 Specify scale for the Paw wave-
form.
Agent prediction
scale
Full range; 0 to 2 xMAC; 0 to 1 xMAC Specify scale for anesthetic gas
prediction.
Flow-volume loop ISO standard; Dräger Specify coordinate axes for
flow/volume loop display.
Headline/
Parameter
Setting range
Description
CO
2;
Paw;
Flow, volume
Default color; color palette with 7 additional
colors
Specify parameter colors.
O
2;
Agent
Default color; ISO color
