Instructions for use Perseus A500 SW 2.0n 71
Assembly and preparation
Breathing bag
Attaching the breathing bag
1 Connect the breathing bag to the breathing bag
hose using the connection nozzle. Attach the
breathing bag hose to the bag elbow.
2 Hang the breathing bag over the hose holder
so that it hangs vertically downwards.
To allow the bag to unfold freely, place it to the
right over the hose holder so that it is not
obstructed by cables or breathing hoses.
Attaching the breathing bag to the flexible arm
(optional)
1 Attach the breathing bag (A) to the elbow.
10346
WARNING
Risk due to pinched breathing bag
If the breathing bag is pinched, excessive
airway pressures or a lack of fresh gas may
result.
When attaching and aligning, pay attention to
the following:
–The breathing bag is visible.
–The breathing bag is not pinched.
–The breathing bag can inflate freely.
10345
