Instructions for use Perseus A500 SW 2.0n 45
Operating concept
Function of the keys on single-arm ceiling supply
units:
A Key (green) has no function.
B Key (blue) to release the brake on the ceiling
bearing
Keep key (A) or (B) pressed while
simultaneously moving the arm system and
Perseus.
Height adjustment
Prerequisite: Remote control is connected to the
ceiling supply unit.
Keep key (C) or (D) pressed and then release it
when the ceiling supply unit has reached the
desired position.
Status display
Depending on the software of the ceiling supply
unit, the following status conditions may be
indicated:
Safety sensor
The ceiling-mounted version of Perseus is fitted
with a safety sensor, see page 19.
The safety sensor is triggered by resistance from
below, e.g., as a result of obstacles such as
objects or persons. When the safety sensor is
triggered, lowering of the ceiling supply unit is
stopped.
To continue lowering the ceiling supply unit after
the safety sensor has triggered, perform the
following steps:
1 Briefly lift the anesthesia machine using the
ceiling supply unit.
2 Make sure that no obstacles are present.
C Up arrow key for lifting the ceiling supply unit
D Down arrow key for lowering the ceiling sup-
ply unit
E LEDs for status indication
Indication Meaning
Green LED lights. The remote control is con-
nected to the ceiling supply
unit and is ready for use.
Indication Meaning
Green LED flashing. The control system of the
ceiling supply unit has a
malfunction.
Red LED lights. The mechanical connection
between Perseus and the
ceiling supply unit is not
working properly.
