Instructions for use Perseus A500 SW 2.0n 157
Configuration
System setup > Therapy
Vertical tab "Vent. 1"
The start settings for VT and RR influence the start
values of the alarm limits for MV high, MV low, and
VTi high:
The "offset" value corresponds to the respective
offset setting for automatic alarm adjustment. The
"offset" value can be set in the System setup >
Alarms > vertical tab Autoset limits.
The following applies in volume-controlled modes:
Headline/
Parameter
Setting range
Description
Default ventilation
mode
Buttons with available ventilation modes
Man/Spon
Specify the default ventilation
mode at start of therapy.
VT and RR start settings Specify the tidal volume and respi-
ratory rate.
Based on Patient category; Ideal body weight
Selected:
[Patient category]
Specify tidal volume and respira-
tory rate based on patient cate-
gory.
VT
[mL]
20 to 2000
500
20 to 2000
150
20 to 2000
50
RR
[1/min]
3 to 100
12
3 to 100
20
3 to 100
30
Selected:
[Ideal body weight]
Specify the tidal volume and respi-
ratory rate based on ideal body
weight.
Set the tidal volume and the respi-
ratory rate for the supporting
points 5; 15; 75; 100 kg (11; 33;
165; 220 lbs).
For calculated values for ideal
body weight values that lie
between these four supporting
points, the start settings for tidal
volume and respiratory rate are
interpolated linearly. For ideal
weight values lying outside these
supporting points, calculation pro-
ceeds with the values of the high-
est or lowest supporting point.
VT
[mL]
20 to 2000
100 kg (220 lbs): 700
75 kg (165 lbs): 520
15 kg (33 lbs): 110
5 kg (11 lbs): 35
RR
[1/min]
3 to 100
100 kg (220 lbs): 10
75 kg (165 lbs): 12
15 kg (33 lbs): 26
5 kg (11 lbs): 32
MV high = VT x RR x (1 + offset);
minimal: 2.0 L/min
MV low = VT x RR x (1 – offset);
minimal: 0.3 L/min
VTi high = VT x (1 + offset)
VTi high = 130 % x VT
