1-20
HDPQ Xplorer UI Touchscreen Features, continued
Housekeeping
functions
(continued)
Battery / Power
Supply Status
Displays battery charge status when powered externally. Displays
battery percent charge remaining when operating from internal
battery as well as charging level if power supply is plugged in to a
valid AC source.
When battery is not charging:
Taskbar displays battery icon indicating the percentage of battery
life that HDPQ Xplorer has remaining.
Battery life:
When battery is charging:
Taskbar displays battery icon indicating the percentage of battery
charge.
Battery charge:
Time/Date
Displays the current time and date. See Chapter 5 Instrument
Settings - Time and Date Settings.
75%100%
50%
25%
0%
100%
75% 50%
25%
0%
HDPQ-106
