6.1.1.1 Mounting on the DIN rail
Step 1:Thetworetainingspringsontheundersideofthedevicemustbepulledoutusingaflat-blade
screwdriver until they click into place.
DANGER
Warning about dangerous electrical voltage! Danger of electric shock!Thesafetyinstructionsand
work safety instructions mustbeobservedforthemounting.Allplugconnectorsmayonlybeinserted
and removed when the power supply is disconnected.

In order to carry out the assembly / dismantling, there must be a distance of at least 8 mm from the
next component (e.g. cable duct), otherwise the retaining springs cannot be pulled out.

