13 Order numbers and accessories of UA 4xx E
13.1 Case Controller
Type Description Order number
UA 401 E CC For 1 Electronic Expansion Valves, int. archive, for DIN rail mounting,
with CAN bus
KGLUA2E012
UA 400 E CC For 2 Electronic Expansion Valves, int. archive, for DIN rail mounting,
with CAN bus
KGLUA4E012
UA 410 E AC For 2 Electronic Expansion Valves, int. archive, for DIN rail mounting,
with CAN bus, real time clock, internal archive, analog inputs and
analog outputs
KGLUA4E016
13.2 Components
Component Description Order number
Temperature sensors
(NTC)
L243 (Standard) 3,0 m
L243 (Standard) 5,8 m
5K3A1 8,5 m
L243 (K243) Block sensor (old design)
KGLZTEMP56
KGLZTEMP58
KGLZ5K3A1
KGLZL243
Pressure transmitter
4..20 mA
0..10 bar
1..26 bar
1..61 bar
1..161 bar
KGLZDRUCK3
KGLZDRUCK4
KGLZDRUCK5
KGLZDRUCK6
Humidity and
temperature sensor
Combined humidity sensor (4..20 mA) and temperature sensor (Pt1000 4-wire) for wall mounting KGLZPTHYGR
Operator Interface
and
Temperature display
BT 300 M Operator Interface handheld operating terminal for service with 2,8 m
connecting cable
BT 300 S Operator Interface for panel mounting
LIBDTUA052
LIBT300S51
Temperature display
BT 30 Temperature display with 7 m connecting cable (RJ45)
RJ45 splitter for the connection of up to four BT 30 on an case controller
BT30LC0002
KGLVERT001
Connector set
UA 400 E CC
UA 401 E CC
UA 410 E AC
STVSETUAB1
STVSETUAB6
STVSETUAB2
USB-A-B cable USB-A-B cable with ferrite core
For direct parameterisation of the case contr. via LDSWin or
For carrying out a firmware update of the case controller or
The parameterisation of system components via CAN bus using LDSWin
PCZKABUSB1
