12.2 Mechanical Data
DIN rail mounting

(A): Connector set with cable
All dimensions in mm
12.3 Mechanical data of the temperature sensor L243 / 5K3A1

All dimensions in mm.
Sensor type / lenght/ order number:
L243
l = 3,0 m (KGLZTEMP56)
l = 5,8 m (KGLZTEMP58)
5K3A1
l = 8,5 m (KGLZ5K3A1 / KGLZ5K3A1S)
Fordetailedinformationofthetemperaturesensorsseedatasheet“Temperature sensors”.
